Parameters and specifications
resistance | 3,100 m / 31,00 m / 310,0 m / 3,100 Ω |
voltage | ±6,000 V / 60,00 V |
temperature | -10 to 60 °C |
test frequency | 1 kHz ±30 Hz |
test current | 160 m / 16 m / 1.6 mA |
- automatic hold and storage of the measured value after it has stabilized
- additional measurement - temperature
- possibility to store up to 6000 sets of measured data in the memory of the instrument
- slot for optional Bluetooth adapter Z3210
- free GENNECT Cross app for Android and iOS
- the app allows, among other things, the sending of measurement data or the backup of stored measurement location information (Profile Information) to cloud storage, allowing colleagues to create measurement reports in near real time from the comfort of their office
- when paired with a tablet/smartphone, the ability to set up an audio measurement guide
- use only original HIOKI fuses
Measurements via mobile app/SW for efficient management of measured UPS:
Direct export of measurement data to Excel:
Downloads and links
- Katalog - měřicí přístroje pro bateriový průmysl.pdf (8950kB)
- Průvodce instalací aplikace Gennect Cross (free app).pdf (3500.2kB)
- Datasheet - BT3554-50.pdf (2123.3kB)
- Further information on the manufacturer's website
