CBA 400M-110 Broadband Amplifier

    • broadband amplifier, 10 kHz to 400 MHz, 110 Watt
    • designed as a Class A linear amplifier with low distortion
    • ideal for BCI testing
    • unconditionally stable and resistant to wiring errors
    • highly reliable gallium arsenide technology
    • remote control capability
    • warranty: 3 years
    Ametek Compliance Test Solutions
    Other parameters
    Price on request
    Cat. no: CBA400M-110.w
    availability on request

    No item matches your selection.

    Parameters and specifications

    frequency range 0.15 to 400 MHz
    rated output power 110 W guaranteed
    output power at 1 db compression 80 W guaranteed (110 W typical below 100 MHz)
    amplification 51 dB
    harmonics at P1 dB better than ±20 dBc
    supply voltage 100-240 VAC, single phase
    • CBA 400M-110, a Class A mismatch-proof amplifier, is designed specifically for EMC testing in the automotive, military and aerospace industries
    • class A design provides high reliability and linear performance with low distortion over the entire frequency range. This design also ensures that the amplifier will operate at full power, even when previously connected to empty or short-circuited
    • amplifier is powered from a high efficiency, high power factor switching power supply that allows operation over a wide voltage range, the unit is air-cooled with integrated fans and is protected against faulty cooling by sensing excessive temperature, there is a safety interlock connector that the user can short to the carcass to place the amplifier in standby mode, there are indicators on the front panel to indicate overtemperature function and RF interlock settings
    • most commonly used for IEC/EN 61000-4-6, CISPR 24, EN 61000-6-1, EN 61000-6-2, IEC 60533, IEC 60601-1-2, IEC 61326, MIL STD 461, RTCA/DO 160, ISO 11452-3, ISO 11452-4, ISO 11452-5, SAE J1113-4, SAE J1113-24 standards
