IG-631OV RF Shielded Box

    • shielded box for temperature chambers for small DUTs
    • up to 12 GHz
    • high efficiency shielding
    • warranty: 1 year
    IGOS-MN RF Shielding
    Other parameters
    Price on request
    Cat. no: IG-631OV.w
    availability on request

    No item matches your selection.

    Parameters and specifications

    internal dimensions (wxhxh) 25x22x21 cm
    outer dimension (wxhxh) 27x27x22 cm
    typical RF shielding 0.1 GHz - 1 GHz > 90 dB
    1 GHz - 3 GHz > 90 dB
    3 GHz - 12 GHz >90 dB
    weight 7 kg
    material stainless steel
    operating temperature -50 ºC to +120 ºC
    power supply 50 VDC, max 3 A
    220 VAC, max 16 A
    • control via modular IO filter panel
    • the box is designed for testing any wireless transmission, such as: Wi-Fi, Bluetooth, RFID, WLAN, GPS and Wimax
