Shielding Tents and Pouches

Shieldex® EMC tents and enclosures are the ideal choice for laboratory tests and measurements in the frequency range from 0.03 to 16 GHz, where they offer shielding up to 95 dB. Thanks to their flexible and lightweight components, Shieldex® shielded tents are portable and can be erected and dismantled in a very short time.

C-Series

size of the tent according to your needs
double or triple layer
materials used depending on the version Shieldex® Nora Dell RS CR, Shieldex® Zell RS and Shieldex® Berlin RS
can be used in clean rooms in accordance with A 300 (class 1000)
shielding up to 95 dB in the frequency range 0.3 to 18 GHz
operating temperatures from -30°C to 90°C
custom logo option

availability on request

Price on request

P-Series

outer frame dimensions 2390 x 2390 x 2300 mm (h x w x d)
internal tent dimensions 2150 x 2150 x 2180 mm (h x w x d)
double or triple layer
- material used Shieldex® Nora Dell RS CR and Shieldex® Berlin RS for double layer
- material used Shieldex® Nora Dell RS CR, Shieldex® Zell RS and Shieldex® Berlin RS for triple layer
can be used in cleanrooms in accordance with A 300 (class 1000)
85 dB average shielding for double layer and 95 dB for triple layer in the frequency range 0.3 to 18 GHz
custom logo option

according to the variant

Price on request
