RFS-1220 RF & Microwave Signal Generator

    • frequencies up to 22 GHz
    • output level up to +15 dBm
    • low phase noise and excellent spectral purity
    • compact design at an affordable price
    • warranty: 1 year
    BNC Berkeley Nucleonics Corp
    Other parameters
    Price on request
    Cat. no: RFS-1220
    availability on request

    No item matches your selection.

    Parameters and specifications

    frequency range 100 MHz to 22 GHz (calibrated up to 20 GHz)
    frequency step < 2 Hz
    output power range -40 dBm to +15 dBm (0.1–13 GHz)
    -22 dBm to +15 dBm (13–22 GHz)
    output power accuracy ±1.0 dB (typ.)
    phase noise -92 dBc at 20 GHz (10 kHz offset)
    harmonic content < -25 dBc (typ.)
    • precise frequency control with fine tuning
    • USB and Ethernet control with SCPI command support
    • USB-C power supply (5 V / 2.0 A)
