SP9900 Split Cable

This cable is useful in cases where the input interface of the device being used does not support dual-channel CAN signal transmission on a single connector. The SP9900 separates CAN channels 1 and 2 and provides them on two separate output connectors.

Detailed Product Overview

The HIOKI SP9900 Split Cable is designed for use with the SP7100 CAN Interface. It separates the two CAN channels provided by the interface into two independent 9-pin D-sub output connectors, allowing each channel to be accessed individually.

This cable is required when the connected measurement system can process only one CAN bus per input, or when different CAN signals need to be routed to separate instruments. Typical examples include setups where one CAN bus provides high-voltage battery data to a HIOKI PW4001 Power Analyzer, while another bus is simultaneously recorded by a data logger such as the HIOKI LR8450.

The SP9900 features a 9-pin D-sub male connector on the input side and two 9-pin D-sub female connectors on the output side. With a total length of approximately 390 mm, it offers sufficient flexibility for orderly and low-strain wiring in bench or in-vehicle environments.
